86343340 PUZZI 50/35 33
Solution
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86173640 11-800437 2 ADPT,3/8 BLKHD COMPLETE
2 86233150 20042 2 CLAMP, 3/8 WORM GEAR
3 86238460 36259 2 HOOK, STRAP
4 86197940 40027 1 HOSEBARB, 3/8 MPT X 1/2 HOSE 90°
5 86001550 40043 1 HOSEBARB, 3/8 MPT X 3/8 HOSE 90°
6 86273740 70010 1 SCR, 1/4-20 X 1.50 HHCS SS
7 86273830 70020 11 SCR, 1/4-20 X 1/2 HHCS SS
8 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
9 86324210 - 4 SCR, 1/4-20 X 5/8 BHCS BLK
10 86276160 70604 2 SCR, 10-32 X 5/8 PPHMS BLK
11 86007970 73864 1 STRAINER, 3/8 IN. NPT 60 MESH
12 86233410 81270 2 CLAMP, 3/4 DIA CUSHION .406 DIA
13 86010670 87029 2 WASHER, 5/16 X 3/4 SS
14 86010630 87013 12 WASHER 1/4 ID X 5/8 OD SS
15 86323330 - 2 WASHER, 1/4 ID X 1.0 OD FLAT BLK
16 86311990 - 1 HINGE, 9.5" LG X .074 THK
17 86312000 - 1 LID, SOLUTION, COVER
18 86312010 - 1 LID, SOLUTION, HINGE BRKT
19 86321370 - 1 TANK, SOL, TRIM
20 86297620 - 2 STRAP, HAND TOOL
21 86317560 - 1 SPACER, .50 ODX .28 ID X 1.0L
22 86318790 - 2 WASHER, 1.032ID X 1.5OD X .062THK
23 86324030 - 2 PLATE, MOUNTING, SOLUTION
