Kärcher T 12/1 User Manual

– 5
Technical specifications
T 12/1
Mains voltage V 120
Frequency Hz 1~ 60
Rated current A 10
Container capacity gal (l) 3.2 (12)
Air volume (max.) CFM (l/s) 129 (61)
Negative pressure (max.) mm (kPa) 2560 (25.1)
Protective class II
Suction hose connection (C-DN/C-ID) in (mm) 1.26 (32)
Length x width x height in (mm) 16.0 x 12.5 x 13.5
(410 x 315 x 340)
Typical operating weight lbs (kg) 14.6 (6.6)
Max. ambient temperature °F (°C) 104 (+40)
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 61
Uncertainty K
pA
dB(A) 1
Power cord SJT 2x18 AWG
Part no.: Cable length
CUL 6.649-248.0 40 ft (12 m)
10 EN

Kärcher T 12/1 Specifications

General

Standard nominal width	- mm
AC input voltage	220 - 240 V
Maximum input power	1300 W
Type	Drum vacuum
Dust capacity	12 L
Product color	Black, Grey, Yellow
Dust container type	Dust bag
Airflow	61 l/s
Noise level	65 dB
Dirt separating method	Filtering

Weight and Dimensions

Depth	315 mm
Width	410 mm
Height	340 mm
Weight	6600 g
