step 1: Use 3mm Allen key to remove two screws shown above.
step 2: Use 5mm Allen key to remove the screw shown above.
Step 3: Take off the armrest assemble.
Step 4: Move the armrest assemble one step forward or backwards.
Now the armrests are set in to a different depth position.
After adjusting the armrest, make sure the user can still access to the
joystick. If the user need more adjustment regarding the relative position
of the user’s hand and joystick, please refer to the control setting chapter.
