11.1.7 Footrest Length
The footrest length should be adjusted according to the user's calf length.
Use 10mm open wrench and 5mm Allen Key from KARMA Tool Kit to loosen
the bolt at the side of the footplate and adjust the footplate height and re-
tighten the bolt. Now the footplates are set in to a different position.
By loosening the second bolt on the footplate, the footplate might
suddenly start to slide down. If the user has his or her foot on the
footplate, this sudden movement might cause a shock reaction.
It is best to hold the footplate with one hand and loosen the bolt with the
other hand.
