CONNECTION TO THE MAINS SUPPLY
Make sure that the supply voltage corresponds with the voltage marked on the rating label. This product
complies with all binding UL labeling directives.
TECHNICAL DATA
Nominal voltage: 220V-240V 50/60Hz
Power consumption: 800W
Max. capacity [Mixing bowl]: 3.5 l
Protection class: II
FEATURES
1. Top cover
2. Mixing bowl
3. Base unit
4. Swivel arm
5. Release knob
6. Switch panel
7. Bottom cover
8. Suction feet
9. Dough hook
10. Flexi beater
11. Egg whisk
UNPACKING AND SETTING UP
• Unpack the appliance from the packaging.
• Remove the transport packaging.
• Check that the appliance shows no signs of damage.
• Place the appliance on a level, dry, nonslip surface so that the appliance can neither fall over
nor slide off.
13
PLANETARY MIXER
