KW5515 LinkSmart Wireless Router User Manual
5
2 Hardware Description
Front Panel
LED
Color
Function
PWR
Blue
Off: Power Not Supplied
On: Power Supplied
WAN\
Blue
On: The WAN port has detected a link with an attached device
Blinking: Data is being transmitted or received by the WAN port
Off: No WAN link via the WAN port
LAN
Blue
On: LAN link established and active via LAN port
Blinking: Data activity occurs
Off: No LAN link via LAN port
WiFi
Blue
On: The 2.4GHz wireless module is ready and idle
Blinking: Data transmitting or receiving over WLAN
Off: The 2.4GHz wireless function is off
WPS
Blue
On: WPS connection is established
Blinking: : Data transmitting or receiving.
Off: WPS function is off or no USB connection
