Kawasaki TH48 - Dimensional Specifications; Engine Layout and Dimensions

WARNING AVERTISSEMENT
READ OWNER'S MANUAL FOR SAFE OPERATION.
POUR VOTRE SECURITE LISEZ LE MANUEL DU PROPRIETAIRE.
´ ´
E
L
E
C
T
R
O
N
I
C
I
G
N
I
T
I
O
N
MARCHE ON
( )
°
4
5
°
°
4
5
°
SHROUD-ENGINE
111 (4.37)
132 (5.20)
MUFFLER
CARBURETOR
SWITCH
STAND
HOUSING - FAN
4 - M6 x 1.0 THROUGH DEPTH 13 (0.51)
P.
C.D Ø100 (3.94)
93 (3.66) 89 (3.50)
4.4 (0.17) ± 1.7 (0.07) 87 (3.43)
SHOE - CLUTCH
AIR - FILTER
14 (0.55) WIDE ( SHOE )
TANK
LEVER - CHOKE
STARTER - RECOIL
CABLE - THROTTLE
DEPTH 13.4 (0.53) ( F/W END )
CLUTCH DRUM INSIDE
DIAMETER Ø78 (3.07)
110 (4.33) 150 (5.91)
R7
(0.28)
Ø88 (3.46) COUNTER-BORE DEPTH 3 (0.12)
CASE
TH48 : DIMENSIONAL SPECIFICATIONS
Unit : mm ( in. )
Consumer Products & Machinery Company KAWASAKI HEAVY INDUSTRIES,LTD. P/N99909-2192 Printed in Japan 02-04(71)
Ø98 (3.
86)
