2 Installation
2.1 Package Contents
 WESII RF Module (Host/AP or Client; WESII-KT comes with one Ptp Host and
one Client)
 One mid-span compliant Power Injector Module for each WESII unit included
 One 24Vdc, 500mA PSU for each power injector module included
 Wall or pole mount bracket and assembly kit for each RF module included
 Quick Start Guide
Consult the Quick Start Guide for the exact list of components for the particular part
number ordered. Please contact you dealer or distributor if a part is missing or
damaged within 10 days of receiving the products.
2.2 Configurations
Products are available in either integrated antenna or external antenna chassis, with
the following configurations:
Part number
Topology type
Unit type
Antenna type
WESII-AA-A*
Ptp
Host
5dBi
WESII-AA-B*
Ptp
Host
9dBi
WESII-AA-C*
Ptp
Host
17dBi
WESII-AA-D*
Ptp
Host
Selectable
WESII-AB-A*
Ptmp
Host
5dBi
WESII-AB-B*
Ptmp
Host
9dBi
WESII-AB-C*
Ptmp
Host
17dBi
WESII-AB-D*
Ptmp
Host
Selectable
WESII-AC-A*
Ptp/Ptmp
Client
5dBi
WESII-AC-B*
Ptp/Ptmp
Client
9dBi
WESII-AC-C*
Ptp/Ptmp
Client
17dBi
WESII-AC-D*
Ptp/Ptmp
Client
Selectable
WESII-KT-*
Ptp
Host & Client
17dBi
Where * denotes the power supply and firmware.
