60.xxx – Niskin Bottles – Manual, ver. 3.00
A correct loaded sampler.
Fasten the sampler to the wire by securing the 2
mounting clamps to the wire – do not over tighten the
clamps so the wire is damaged.
Align the small pin of the mounting clamp to fit into
the small slot in the bracket.
Loading the sampler (only for 1,7
and 2,5 L)
The small Niskin bottles have no handle, and first you
must secure the upper wire as shown.
Attach the other wire to the first wire. It is very
important, that the lids have an offset as shown, 90
degrees, approx. Otherwise it may not release
correctly.
