KDK 20AUH - Parts List

4. Parts List
10
20AUH
No. Part No. Part Name Q'ty Remark
1 FFV5510016H Shutter (Small) 2
2 FFV5510017H Shutter (Big) 1
3 FFV5520008H Shutter Set Plate 2
4 FFV7010013S Washer 1
5 FFV5560014S Shutter Spring 1
6 FFV0710013H Coupling Rod 1
7 FFV4600001H Plastic Rivet 4
8 FFV7000005S Set Screw 8
For Fixing Shutter Set Plate & Motor Assy.
9 FFV1600075S Frame Assy. 1
10 FFV7010002S Plain Washer 1 For Fixing Earth Lead
11 FFV7010028S Spring Washer 1 For Fixing Earth Lead
12 FFV7000006S Bind Screw 1 For Fixing Earth Lead
13 FFV4300116S Orifice Assy. 1
14 FFV0400084S Blade 1 Gray
15 FFV5500017S Spinner 1
16 FFV0760026S Condenser Box 1
17 FFV0740009S Cord Clip 2 For Fixing Power Cord & Motor Lead
18 FFV7000073S Truss Screw 6 For Fixing Cord Clip & Condenser Cover
19 FFV0970006S Condenser Cover 1
No. Part No. Part Name Q'ty Remark
20 FFV3700260S Motor Assy. 1 For 220-240V,50Hz
(20) FFV3700269S Motor Assy. 1 For 110-127V,60Hz
21 FFV0750150S Condenser 1 250V,2.7uF,For 220-240V,50Hz
(21) FFV0750159S Condenser 1 250V,2.0uF,For 110-127V,60Hz
22 FFV0900024S Connector 2
23 FFV3470001S Butt Connector 1
24 FFV4620024S Power Cord 1
No. Part No. Part Name Q'ty Remark
25 FFV4020158S Name Plate 1 Sticked on Frame Assy.,For Style A
(25) FFV4020159S Name Plate 1 Sticked on Frame Assy.,For Style B
(25) FFV4020160S Name Plate 1 Sticked on Frame Assy.,For Style C
26 FFV4710172S Pad A 4
27 FFV4650010S Poly Cover 1 For Main Body Packing
28 FFV4710128S Paper Pad 1
29 FFV9000436S Packing Case Assy. 1 For Style A
(29) FFV9000437S Packing Case Assy. 1 For Style B
(29) FFV9000438S Packing Case Assy. 1 For Style C
30 FFV0010148S Accessory Set 1
Mechanical & Metal Section
Electrical Section
Packing & Accessories & Label Section
!
!
!
!
!
!
!
!
