KDK SM30H - Installing the Rear Guard; Installing the Front Guard

How to assemble
組裝方法
d
c
1
9
SM30H
1
移除保護網停止器
螺帽
I
。
1
Remove the guard
stopper nut
I
.
2
對齊 3 個凸桿
c
及 3 個孔洞
d
，然後將後保
護網
F
裝入馬達。
3
擰緊保護網停止器螺帽
I
。
■
注意事項 :
․
確切地擰緊保護網停止器螺帽，確保電風扇運作時不會鬆脫。
2
Align each of 3 projections
c
and 3 holes
d
,
then fi x the rear guard
F
to the motor.
3
Tighten the guard stopper nut
I
.
■ Attention:
• Tighten the guard stopper nut securely, not to be
loosened during operation.
將遙控器支架
B
安裝在架子的背面。
Attach the remote control holder
B
at rear
side of the stand.
k
1
打開前保護網的夾子
h
。
1
Open the clip
h
of the
front guard.
3
對齊和將線材完全插入前
保護網及後保護網四周。
3
Align and insert all the
way around of the front
and rear guard.
2
對齊前保護網的鉤子
i
與
後保護網頂部的配合標記
j
，然後插入線材
k
。
2
Align the hook
i
of
front guard with the
marked spot
j
at the
top of rear guard, then
insert the wire rod
k
.
4
如圖接合夾子
h
，以固
定前保護網及後保護網。
4
Engage the clip
h
to
fi x the front and rear
guard as shown in the
fi gure.
1
2
2
3 4
3
B
I
I
F
■
注意事項 :
․
當打開夾子，請小心不要弄傷手指。
․
將線材完全插入保護網四周，並確切地接合夾子，確保電風扇運作時不會鬆脫。
■ Attention:
• When opening the clip, please be careful not to hurt your fi ngers.
• Insert all the way around of guard and engage the clip securely, not to be loosened during operation.
h
h
i
j
■
安裝後保護網
■
Installing the rear guard
■
裝上遙控器支架
■
Attach the remote control holder
■
安裝前保護網
■
Installing the front guard
2
5
3
