Keeler PSL Classic User Manual

10. Names of controls and componen
Portable Slit Lamp illumination body and magnification opti
10.
Magnification change lever (PSL Classic only)
Push this lever to the right to set the magnification at 10x and to the left to set the magnifi
at 16x.
11.
Alternative power socket
In addition to charging through the base charger unit, the device can also be charged throu
this socket.
12.
Charging LED
The yellow charging LED is on continuously during normal charging and blinks when trickle charging.
Trickle charging can occur at the start of charging a completely discharged battery or when attempting
to charge a completely charged battery.
13.
Battery state LED
The yellow battery state LED blinks when the battery is almost empty.
14.
Brightness adjustment wheel
Rotating this wheel clockwise increases the brightness of the illumination lamp. Rotating
this wheel anti-clockwise decreases the brightness of the illumination lamp.
Portable Slit Lamp base charger unit
17
15.
Power socket for Keeler 12V Power Supply
Connect the power supply cable to this socket and the place the slit lamp body in the
charger unit to charge the device.
16.
Recharging connection pins
Connects the slit lamp body to the charger unit to charge the device.
17.
Recess for slit lamp body
Place the slit lamp body in the charger unit when not in use.
18.
Grooves for power cable
15
Place the power supply cable in the most suitable groove to keep the unit tidy.
19.
Protective rubber feet
Ensures the surface onto which the charger unit is placed does not become scratched.
20.
Charging safety feature
Note: No electrical power is conducted through the pins (16) until the slit lamp body is
placed into the recess of the charger unit.
10
14
13
16 11 12
18
19
Home Bac k Next 15
