11. Instructions for use
Preparing the power supply and the base unit
1. Attach the appropriate mains plug adapter to the transformer after
removing the blanking plate or if required use an IEC 60320 type
7 connector (not supplied).
2. Connect the output power supply cable to the socket on the
underside of the recharging base unit.
3. Place the Portable Slit Lamp on the base charger unit, the
yellow LED will illuminate to indicate the unit is being
charged. From fully discharged to fully charged usually takes
2.5 hours.
Illumination ‘on time’ 50 minutes
(when used at full intensity from fully charged)
IEC 60320 TYPE 7 connector
