10
ASSEMBLY INSTRUCTIONS
INSTALLING REAR AXLE
STEP 1: Position rear axle on
Stroller Wagon frame with locking tabs
facing outward as shown below.
STEP 2: Lift locking tabs on each side and
secure the axle to the frame of
the Stroller Wagon.
STEP 3: While lifting locking tabs,
push axle assembly down on frame
as shown.
STEP 4: Axle shown properly
locked to Stroller Wagon frame.
STEP 1: Push button on wheel
center as shown.
STEP 2: While keeping button pushed,
slide wheel onto axle rod. Release
button to lock wheel in place.
INSTALLING REAR WHEELS
