If your PC has VGA video output, purchase a VGA cable and connect it between the VGA input of the monitor and
the VGA output of the PC.
Audio Jack 3.5mm input
If you want to play the music through the monitor’s internal speakers while the PC is connected to the monitor via
VGA cable, connect a 3.5mm Jack cable between the 3.5mm Jack audio input of the monitor and the PC’s audio
output. Note: Input available only if monitor and PC are connected via VGA cable)
DC input
Connect the supplied power cable to the DC input of the Monitor and connect the adapter to a household electrical
outlet. Power adapter: 12VDC/2.5A
Button functions
On / Off button: If you want to turn on the monitor press the on / off button, if you want to turn off the monitor
press it again.
M button: OSD menu is displayed on the screen. Once inside, it also has the function of accepting or accessing the
interior functions.
Button E: Exit the current menu or exit the OSD menu.
Up / Down direction buttons: The up and down direction button allows you to move between the different menus
and modify values. If you are not in the OSD Menu, below allows you to enable / disable (HDR) High dynamic range,
above allows you to modify the contrast of the monitor.
Technical Specifications external power adapter
Commercial registration number
C/Tecnología, 5, 41120, Gelves, Seville, Spain
Description Model identifier
AC/DC adapter for XGM24V7
Average active efficiency
Low-load efficiency (10%)
