KEF Ci3-80QT - Closed Position Adjustment

Closed Position:
When the Ci200.3QT is closed there should be a 1 or 2 mm gap between the
carriage and the outer trim. If it is closed tight with no gap it is a sign that the
limit switch is not tripping. To adjust the limit switch you can adjust the screws
as shown Or use a long nose plier to gently flex the spring steel of the switch to
cause the switch to engage sooner.
www.KEF.com
Correct
Not Correct
