Model
CCRREESSTTAA 3300 CCRREESSTTAA 1100 CCRREESSTTAA
2200cc
Design Two way floorstanding Two way bookshelf Two way centre
Drive Units HF: 25mm (1”) silk HF: 25mm (1”) silk HF: 25mm (1”) silk
dome tweeter dome tweeter dome tweeter
LF: 130mm (5
1
4”) LF: 130mm (5
1
4”) LF: 100mm (4”) coated
coated paper cone coated paper cone paper cone x 2
Frequency response at 15˚
horizontally off axis ± 3dB 45 Hz - 20kHz 52 Hz - 20kHz 60 Hz - 20kHz
LF Corner – 6dB 40 Hz 47 Hz 55 Hz
Crossover frequency 3kHz 3kHz 3kHz
Power Handling 100 W 100 W 120 W
Amplifier (into 4)
1
10 - 100 W 10 -100 W 10 - 120 W
Sensitivity (2.83V/1m) 90 dB 90 dB 90 dB
Maximum output 108 dB 108 dB 108 dB
Impedance 8 8 8
Magnetic shielding No No Yes
Internal volume 18 litres (0.63 cu ft) 8.5 litres (0.3 cu ft) 7.2 litres (0.25 cu ft)
Weight 11 kg (24.2 lbs) 5 kg (11 lbs) 6 kg (13.2 lbs)
Dimensions * 825 x 185 x 242 mm 305 x 185 x 242 mm 145 x 405 x 210 mm
(H x W x D) 32.4 x 7.2 x 9.5 in. 12 x 7.3 x 9.5 in. 5.7 x 15.9 x 8.2 in.
KEF AUDIO (UK) Limited, Maidstone, Kent. U.K.
Telephone: +44 (0) 1622 672261 Fax: +44 (0) 1622 750653
www.kef.com
5
(GB) Specifications
(F) Spécifications
(D) Technische Merkmale
(I) Specifiche
(ES) Especificaciones
(P) Especificações
(NL) Technische gegevens
(DK) Specifikationer
1
AMP - The range of suitable amplifier power ratings assumes the programme material to be typical music and speech and that the amplifier is not run
into clipping.
* Including grille
