Keithley 2260B-80-13 Adjustment Manual

Series 2260B
Programmable Power Supplies Verification and Adjustment Manual Section 5:
Verification test record forms
077104802 / November 2016 5-5
Constant current tests:
Current programming
and measurement
Model Minimum
specifications
Results Maximum specifications
Minimum current out 80-13 -10 mA +10 mA
80-27 -30 mA +30 mA
80-40 -40 mA +40 mA
Measurement accuracy 80-13 -20 mA +20 mA
80-27 -40 mA +40 mA
80-40 -50 mA +50 mA
Rated current out 80-13 12.87 A 13.13 A
80-27 26.943 A 27.057 A
80-40 39.92 A 40.080 A
Measurement accuracy 80-13 12.967 A 13.033 A
80-27 26.933 A 27.067 A
80-40 39.91 A 30.09 A
CC load regulation Model Minimum
specifications
Results Maximum specifications
80-13
-18 mA
+18 mA
80-27
-32 mA
+32 mA
80-40
-45 mA
+45 mA
CC line regulation Model Minimum
specifications
Results Maximum specifications
80-13
-18 mA
+18 mA
80-27
-32 mA
+32 mA
80-40
-45 mA
+45 mA
