GETTING STARTED
17
720W: 2260B-250-9, 800-2
LAN
100 240V
1000VA MAX.
AC
47 63Hz
SER.NO. LABEL
V SN.C. S V
Output
terminals +V
Fan
Chassis
ground
USB B
port
LAN
AC Input
Sense-
terminal
Analog control
connector
Sense+
terminal
Output
terminals -V
1080W: 2260B-250-13, 800-4
360W: 2260B-250-4,
800-1
LAN
LN
SER.NO. LABEL
47 63Hz
1500VA MAX.
AC 100 240V
V VSN.C. S
AC Input
LAN
100 240V
47 63Hz 500VA MAX.
AC
V SN.C. S V
