Slew Rate
Only the master unit’s current or voltage
slew rate settings apply.
The settable current slew rate is double or
triple that of a single unit, depending on the
number of units that are used in parallel.
For example:
The 2260B-30-36 has a maximum settable
current slew rate of 72A/S. When two 2260-
30-36 units are used in parallel, the
maximum settable slew rate setting is
144A/S.
Internal Resistance
Only the master unit’s internal resistance
settings apply.
For 2 units in parallel, the internal resistance
is actually half of the setting value.
For 3 units in parallel, the internal resistance
is actually a third of the setting value.
Bleeder Control
The master unit is used to control the bleeder
settings. The bleeder resistors in all the slave
units are always turned off when in parallel
mode.
