OPERATION
61
Master with 1 slave unit:
2
12
131517
20
21
24 20 12
17 15 3
23
OUTPUT ON STATUS
21
Master unit
ALM STATUS
20
STATUS COM
17
FEEDBACK
15
CURRENT_SUM_1
13
SHUTDOWN
12
OUT ON/OFF CONT
24
Slave Unit 1
12 SHUTDOWN
20 ALM STATUS
15 FEEDBACK
3 CURRENT SUM OUT
17 STATUS COM
2 D COM
11 1I MON CURRENT SHARE
11
1
Parallel Output
Connection
-
+
Load
Master
unit
Slave
unit 2
Slave
unit 1
Steps
1. Ensure the power is off on all power supplies.
2. Choose a master and a slave unit(s).
3. Connect the analog connectors for the master
and slave unit as shown above.
4. Remove the Output Terminal
covers and the protection dummy
plug from the analog control
connector.
Page 36
