Keithley 2306 Quick Results Guide

Front panel operation 17
Charger channel (#2)
Command Description
SENS2:RANG 5 ‘ Select 5A range.
SOUR2:VOLT 15 ‘ Set output voltage to 15V.
SOUR2:CURR 0.75 ‘ Set current limit to 750mA.
OUTP2 ON ‘ Turn output on.
SENS2:PCUR:SYNC ON ‘ Enable trigger synchronization.
SENS2:PCUR:AVER 10 ‘ Set average count to 10.
SENS2:PCUR:SYNC:TLEV 0.1 ‘ Set trigger level to 100mA.
SENS2:PCUR:TIME:AUTO ‘ Set integration times automatically.
SENS2:PCUR:SYNC:DEL 50e-3 ‘ Set trigger delay to 50msec.
SENS2:FUNC “PCUR” ‘ Select pulse current function.
SENS2:PCUR:MODE HIGH ‘ Configure to measure peak pulse (trigger on).
READ2 ‘ Trigger 10 measurement conversions and return the
average of those 10 conversions. The average of the
10 conversions is displayed on the front panel. Each
of the ten conversions syncs to the rising edge.
