Model 2306
Quick Results Guide
NOTE
This quick results guide provides information on five different models of battery or
battery/charger simulators (Models 2302, 2302-PJ, 2306, 2306-PJ, and 2306-VS).
In this guide, references to Model 2306 apply to all of the simulators unless
otherwise noted. Likewise, references to specific models (for example, Model 2306,
2306-PJ, or 2306-VS, or Model 2302 or 2302-PJ) refer only to the models listed.
Since the Model 2302 and 2302-PJ are single channel battery simulators, functions
related to the second channel (i.e., the charger channel) are not available for these
models. Therefore:
• battery and charger channel features contained in this manual apply for
the Models 2306, 2306-PJ, and 2306-VS
• only battery channel features contained in this manual apply for the
Models 2302 and 2302-PJ
References to the Model 2302 also apply to the Model 2302-PJ unless otherwise
noted. Refer to Appendix F of Instruction Manual (2306-901-01) for specific
Model 2302 and 2302-PJ information.
Information contained in this guide applies to all power supply channels (unless
otherwise noted). In this manual, channel 1 refers to the battery channel while
channel 2 refers to the charger channel (2306, 2306-PJ, and 2306-VS features only).
For additional information on any feature discussed in this guide (including
programming examples), refer to the Instruction Manual (part number
2306-901-00).
