2.2
C
onnec
tion of syst
em
2.2.1
W
ater cooled syst
em: F
astM
ig power sour
ce + MXF + F
astCool 10
1.
4.
8.
2.
3.
9.
5.
6.
7.
1.
MXF wire feed unit
2.
F
astM
ig power sourc
e
3.
F
astCool water cooler and power c
onnection
4.
Gas supply
5.
MMA electrode holder
6.
Remote control devic
e
7.
Liquid cooled welding Gun
8.
Po
wer cable
9.
Earth return lead and clamp
5
© Kemppi Oy / 1336
6
