Kenko Sky Memo - Kenko Sky Memo Specifications

Kenko Sky Memo Instructions
Hutech Corporation © 2000
5
Specifications
Tracker:
Operation Northern or Southern hemisphere (switchable
by N-S switch)
Weight 3kg (Mount plus camera arm)
Dimensions 240mm long x 90mm wide x 130mm high
Load capacity 2.5kg at each end. Total 5 kg.
Attachment M8 screws included for Kenko tripod or ¼-20
camera screw hole for standard photo tripod
Polar scope Magnification: 4X
Actual field of view : 10 degrees
Accuracy: better than 5’
Illuminated reticle, northern and southern
hemisphere operation
Polar scope filter thread M30.5/P0.5
Motor type Stepper
Gears 1:500, 1:2, Worm: 1:144
Hand controller 2X or stopped
Power 6VDC (4 c-cells)
Battery life >24 hours (Manganese batteries @ 20
degrees C)
Optional Tripod:
Height 600 to 800 mm
Weight 4 kg
Load capacity 10 kg
Azimuth range 30 degrees
Altitude range -10 degrees to 50 degrees
