Kenmore 401.85053010 - User Manual

Questions and Answers

J
Jason EscobarAug 9, 2025
What to do if my Kenmore Microwave Oven shows a sensor open error?
- A
  Alexander BellAug 9, 2025
  If your Kenmore Microwave Oven displays a 'Sensor open error', the issue might stem from an unplugged sensor, faulty wiring, or a problem with the smart board. Begin by inspecting the sensor and its wiring. If these appear normal, replacing the sensor might resolve the error. However, if the error surfaces specifically when initiating a sensor function, replacing the smart board is recommended.
H
Heather PorterAug 19, 2025
What to do if my Kenmore 401.85053010 Microwave Oven displays a sensor short error?
- K
  Kelly AndersonAug 20, 2025
  If your Kenmore Microwave Oven displays a 'Sensor short error', the issue might be a shorted sensor or a problem with the smart board. Begin by checking the sensor. If it appears shorted, replacing the sensor might resolve the error. However, if the error surfaces specifically when initiating a sensor function, replacing the smart board is recommended.
W
watsonjohnAug 29, 2025
How to fix a key short error on a Kenmore Microwave Oven?
- B
  barrettjamesAug 29, 2025
  If your Kenmore Microwave Oven is showing a 'Key short error', the solution is to replace the assy control panel or the smart board.

Summary

MICROWAVE OVEN

FEATURES

Overview of the microwave oven's capabilities and functions.

1. Precaution

General Safety Precautions

Essential safety measures to prevent hazards during operation and servicing.

1-1 Safety precautions

Detailed safety guidelines and warnings for handling the microwave oven.

1-2 Special High Voltage Precautions

Critical safety procedures related to high voltage components and potential risks.

3. Operating Instructions

3-1 Control Panel

Explanation of the microwave oven's control panel layout and functions.

4. Installation

Mounting and Venting

Instructions for properly installing the microwave oven, including mounting and vent configurations.

5. Disassembly and Reassembly

5-1 Replacement of High Voltage Transformer

Step-by-step guide for replacing the high voltage transformer.

5-2 Replacement of Magnetron

Procedures for safely removing and replacing the magnetron component.

5-3 Replacement of Fan Motor

5-4 Replacement of Door Assembly

5-8 Replacement of Control Circuit Board

6. Alignment and Adjustments

6-1 High Voltage Transformer

6-2 Magnetron

6-3 High Voltage Capacitor

6-4 High Voltage Diode

6-6 Adjustment of Primary Switch, Door Sensing Switch and Monitor Switch

6-8 Thermal Cutout (TCOS)

6-9 Output Power of Magnetron

Method for measuring magnetron output power using a water temperature rise test.

6-10 Procedure for Measurement of Microwave Energy Leakage

Step-by-step guide for measuring microwave energy leakage.

6-11 Check for Microwave Leakage

Procedure to verify microwave leakage levels using a survey meter.

6-14 Sensor

7. Troubleshooting

7-1 Electrical Malfunction

Troubleshooting guide for electrical issues and non-operation of the oven.

Timer Issues

Noise and Cooking Issues

7-2 Error Code List

List of error codes and their corresponding causes and countermeasures for the gas sensor.

8. Exploded Views and Parts List

8-2 Main Parts List (85052)

8-3 Main Parts List (85053)

8-4 Main Parts List (85059)

Kenmore 401.85053010 Specifications

General

Brand	Kenmore
Model Number	401.85053010
Wattage	1000 Watts
Color	Stainless Steel
Turntable Diameter	12.4 inches
Pre-Programmed Settings	Yes
Child Safety Lock	Yes
Power	120V, 60Hz
Control Type	Electronic
Cooking Modes	Microwave, Defrost
Type	Countertop Microwave Oven
