8-3 RESISTANCE SPECIFICATION OF SENSORS
The resistance of the SENSOR has a ± 5% tolerance dif
ference.
Measure the resistance of the SENSOR after leaving it for over 3 minutes in the measur
ing temperature.
This delay is necessary due to sensor response speed.
¥ Measure the F-SENSOR, SUPER FROST SENSOR, R1, R2-SENSOR after disconnect CON5 of PWB AS
SY, MAIN.
TEMPERATURE
RESISTANCE OF FREEZER RESISTANCE OF REFRIGERATOR &
SENSOR DEFROST SENSOR & ROOM SENSOR
- 20 °C 22.3 K 77 K
- 15° C 16.9 K 60 K
- 10° C 13.0 K 47.3 K
- 5° C 10.1 K 38.4 K
0 °C 7.8 K 30 K
+ 5° C 6.2 K 24.1 K
+ 10° C 4.9 K 19.5 K
+ 15° C 3.9 K 15.9 K
+ 20° C 3.1 K 13 K
+ 25° C 2.5 K 11 K
+ 30 C 2.0 K 8.9 K
+ 40 C 1.4 K 6.2 K
+ 50 C 0.8 K 4.3 K
