33
Care & Cleaning
Removing and Replacing the Drawer
Figure 2
Figure 1
Lever
Lever
Left Glide
Right Glide
Pull up lever
with fi nger
Push down
lever with
fi nger
To Remove the Drawer:
1. Open the drawer to the fully opened position.
2. Locate glide lever on each side of drawer, pull up on the
left glide lever and push down on the right glide lever (See
Figure 1).
3. Pull the drawer away from the range.
To Replace the Drawer:
1. Pull the plastic slider to the front of the glide slots on
each side of the drawer cavity (See Figure 2).
2. Align the glide on each side of the drawer with the
drawer cavity glide slot.
3. Push the drawer into the drawer cavity until glide levers
“click” (approximately 2”). If you do not hear the glide
levers “click” or the drawer does not feel seated
remove the drawer and repeat steps 1 thru 3.
Halogen
Light Bulb
Lift up and pull out.
Replacing the Halogen Oven Light
The oven lights will automatically turn ON when the oven
door is opened. The oven lights may also be manually
operated by pressing the
pad.
The oven light bulb is covered with a glass shield. The
glass shield can be removed to be cleaned manually or to
change oven light. THIS GLASS SHIELD MUST BE IN PLACE
WHENEVER THE OVEN IS IN USE.
To replace the light bulb:
BE SURE THE OVEN IS COOL.
1. Turn the power off at the main source.
2. Wear a leather-faced glove for protection against
possible broken glass.
3. To remove the glass shield, lift up on side and use force
to pull shield out.
4. Replace halogen light appliance bulb taking care not
to touch the bulb with your bare fi ngers. Touching bulb
with your skin can leave a fi lm on the bulb that causes
it to burn out quickly.
5. Replace glass shield in opposite order and manner of
removal.
