Brush Assembly C4-A
Part #
Description
Qty
Notes
10001
Housing, Brush/Alum. Casting
1 ea
10002
Clip, Nozzle-Rear
1 ea
10004
Bolt, 6-32 x 1/4 Phil SS
2 ea
10005
Washer, Lock #6 SS
2 ea
10008
Strap, Motor Brush
2 ea
10009
Pulley, Threaded-Motor
1 ea
10011
Belt, Gear
1 ea
10016
Bracket, Brush
1 ea
10018
Rivet, Alum 5/32 x 1/4
4 ea
10025
Gasket, 2 Part-Brush/Sw. Panel
1 ea
10031
Clip, Nozzle-Front
1 ea
10038
Brass, Plug 1/4 Barb
1 ea
10040
Brass, T-1/4 x 1/4 x 1/4 Barb
1 ea
10057
Clamp, 1/4 Sol. Hose-Zinc
5 ea
10150
Bolt, 10-24 x 1/2 Phil SS
1 ea
10152
Bolt, 10-32 x 3/8 Hex Ground, Grn
1 ea
10158
Wire, Tie-6"
2 ea
10164
Washer, Flat #8 SS
2 ea
10174
Washer, Lock #10 SS
6 ea
10182
Bolt, 10-24 x 3/4 Hex SS
2 ea
10188
Clamp, 1/4 Sol. Hose SS
1 ea
10190
Bolt, 10-24 x 1/2 Hex SS
2 ea
10242
Spray Tip, Quick Dry
2 ea
10250
Hose, Solution-90D Elbow to T - 1/4 I.D. x 2 3/8
2 ea
10251
Hose, Solution-Plug to T - 1/4 I.D. x 21
1 ea
10256
Hose, Vac Nozzle to Disconnect with Cuff
1 ea
10077
Cuff, Hose-Female, Black
1 ea
10255
Hose, Vac Nozzle to Disconnect 1 1/4 I.D. x 21
1 ea
10274
Bolt, 8-32 x 5/16 Phil SS
3 ea
10275
Washer, Flat #10 SS
4 ea
18005
Motor-Brush Wired C4 115 Volt Assembly
1 ea
NFS
Motor, Brush C-4 115 Volt, Unwired
1 ea
10104
Terminal, Spade-Male
2 ea
10131
Terminal, Ring #10
1 ea
10199
Tag, Wire B/Brush Motor (C4)
1 ea
18008
Wire, Ground Housing Brush Assembly
3 ea
10107
Terminal, Bullet Female-Ground
1 ea
10131
Terminal, Ring #10
1 ea
18010
Brass, Elbow 90 D
2 ea
18018
Bumper, Assembly
1 ea
18210
Brush Core Sub-Assembly
1 ea
10010
Pulley, Set Screw-Shaft
1 ea
10012
Shaft, Brush
1 ea
10013
Brush, Reel With Flange
1 ea
10183
Washer, Brush Core
2 ea
10174
Washer, Lock #10 SS
2 ea
10182
Bolt, 10-24 x 3/4 Hex SS
2 ea
18016
Bearing Block Assembly
2 ea
10014
Bearing, Cap (metal)
1 ea
10017
Bearing, Ball SS
1 ea
10195
Bearing, Block (clear rubber)
1 ea
19
