Kenwood TK-2202 User Manual

TK-2202/2206
PARTS LIST
14
∗
New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K: USA P: Canada
Y: PX (Far East, Hawaii) T: England E: Europe
Y: AAFES (Europe) X: Australia M: Other Areas
Parts No. Description Address
New
parts
Destination Destination
TK-2202/2206
Ref. No.
Parts No. Description
Address
New
parts
TK-2202/2206 (Y50-5890-XX)
TX-RX UNIT (X57-6870-20)
Ref. No.
AK : TK-2202 (K) AM : TK-2202 (M) BM : TK-2206 (M)
11A∗ A02-3851-23 CABINET ASSY(16CH) BM
11A∗ A02-3852-23 CABINET ASSY(8CH) AK,AM
21A∗ A02-3858-13 CABINET
33A∗ A10-4078-01 CHASSIS
41B∗ A21-1644-13 DRESSING PANEL(16CH) BM
41B∗ A21-1645-13 DRESSING PANEL(8CH) AK,AM
6 2C,2E ∗ B09-0680-03 CAP(SP/MIC) ACCESSORY
72B∗ B11-1817-04 ILLUMINATION GUIDE
81B∗ B43-1156-04 BADGE
91C∗ B62-1762-00 INSTRUCTION MANUAL AK,AM
10 1E ∗ B62-1763-00 INSTRUCTION MANUAL BM
11 1A ∗ D10-0649-03 LEVER
12 1A ∗ D21-0863-04 SHAFT
13 1A ∗ D32-0441-03 STOPPER
14 2A ∗ E04-0451-05 RF COAXIAL RECEPTACLE(SMA)
15 3B ∗ E23-1253-04 TERMINAL(BATT-)
16 2B E37-0794-05 PROCESSED LEAD WIRE(SP+)
17 2B E37-0803-05 PROCESSED LEAD WIRE(SP-)
18 3A ∗ F20-3353-14 INSULATING SHEET(CHASSIS BATT+)
19 2A ∗ G01-4542-04 COIL SPRING(LEVER)
20 1A ∗ G01-4543-04 COIL SPRING(STOPPER)
21 2B ∗ G10-1330-04 FIBROUS SHEET(IC302:AUDIO IC)
22 3A ∗ G11-4283-04 RUBBER SHEET(Q106:FINAL FET)
23 2A ∗ G11-4313-04 SHEET(MIC ELEMENT)
24 3B ∗ G11-4318-04 SHEET
25 3A ∗ G11-4320-14 SHEET
26 2B,3B ∗ G11-4322-04 SHEET
27 2A ∗ G11-4323-04 SHEET
29 3B ∗ G13-2009-04 CUSHION(TERMINAL BATT-)
30 3A ∗ G13-2033-04 CUSHION(TERMINAL BATT-)
31 3B ∗ G13-2034-14 CUSHION(CHASSIS)
32 2B ∗ G13-2037-04 CUSHION(CHASSIS VOL/CH)
33 3A ∗ G13-2038-04 CUSHION(CHASSIS-CERAMIC FILTER)
34 2A ∗ G13-2039-04 CUSHION(PCB-CERAMIC FILTER)
35 3A ∗ G53-1604-03 PACKING(CHASSIS)
36 3A ∗ G53-1605-03 PACKING(TERMINAL BATT+)
37 2B ∗ G53-1606-03 PACKING(VOL/CH/LED)
38 1B ∗ G53-1607-03 PACKING(SP/MIC)
39 2B ∗ G53-1608-03 PACKING(SP)
40 2A ∗ G53-1609-14 PACKING(MIC ELEMENT)
41 2B ∗ G53-1610-04 PACKING(SMA)
43 2C,2F ∗ H12-3158-05 PACKING FIXTURE
44 1D ∗ H13-2109-03 CARTON BOARD AK,AM
45 1C,1E H25-0085-04 PROTECTION BAG (100/200/0.07)
46 3D ∗ H52-2017-02 ITEM CARTON CASE AK,AM
47 3F ∗ H52-2034-02 ITEM CARTON CASE BM
48 2C,2F ∗ J19-5472-03 HOLDER(SP/MIC) ACCESSORY
49 2A ∗ J19-5473-03 HOLDER ASSY(TERMINAL BATT+)
50 2B ∗ J21-8477-04 HARDWARE FIXTURE(VOL/CH)
51 2B ∗ J21-8478-04 HARDWARE FIXTURE(SP/MIC)
52 2C,2F ∗ J29-0713-05 BELT CLIP ACCESSORY
54 2B ∗ J82-0092-05 FPC
56 1A ∗ K29-9307-03 BUTTON KNOB(SIDE1/SIDE2)
57 1A ∗ K29-9308-03 BUTTON KNOB(PTT)
58 1B ∗ K29-9309-03 KNOB(VOL)
59 1B ∗ K29-9318-03 KNOB(CH)
A2B∗ N14-0808-04 CIRCULAR NUT(CH KNOB)
B2B∗ N14-0812-04 CIRCULAR NUT(VOL KNOB)
C 2A,2B N30-2604-46 PAN HEAD MACHINE SCREW(SMA)
D3AN30-2606-46 PAN HEAD MACHINE SCREW
(CHASSIS)
E 2A,2B,3B N83-2005-46 PAN HEAD TAPTITE SCREW(PCB)
60 1C,2F ∗ N99-2043-05 SCREW SET ACCESSORY
61 2B ∗ R31-0653-05 VARIABLE RESISTOR(POWER SW/VOL)
62 2B ∗ S60-0427-05 ROTARY SWITCH(16CH) BM
62 2B ∗ S60-0428-15 ROTARY SWITCH(8CH) AK,AM
63 1B T07-0369-05 SPEAKER
64 1C T90-1036-05 HELICAL ANTENNA ACCESSORY AK,AM
65 2D ∗ W08-0969-05 CHARGER ACCESSORY AK,AM
66 1D ∗ W08-0970-05 AC ADAPTER(AC120V) ACCESSORY AK
66 1D ∗ W08-0971-05 AC ADAPTER(AC230V) ACCESSORY AM
D403 B30-2156-05 LED(RED)
D404 B30-2157-05 LED(YELLOW)
C1 CK73HB1H332K CHIP C 3300PF K
C2 CK73HB1C682K CHIP C 6800PF K
C3 CK73GB1A105K CHIP C 1.0UF K
C4 CK73HB1C103K CHIP C 0.010UF K
C5 CK73HB1H102K CHIP C 1000PF K
C6 CK73HB1A104K CHIP C 0.10UF K
C7 ,8 CC73HCH1H101J CHIP C 100PF J
C9 CC73HCH1H100D CHIP C 10PF D
C10 C92-0713-05 CHIP-TAN 10UF 6.3WV
C11 CC73HCH1H101J CHIP C 100PF J
C12 CK73HB1H102K CHIP C 1000PF K
C13 CK73HB1A104K CHIP C 0.10UF K
C14 CK73HB1C103K CHIP C 0.010UF K
C15 CC73HCH1H100D CHIP C 10PF D
C16 CK73HB1H102K CHIP C 1000PF K
C17 CC73HCH1H470J CHIP C 47PF J
C18 CC73HCH1H180J CHIP C 18PF J
C19 CK73HB1A104K CHIP C 0.10UF K
C21 C92-0713-05 CHIP-TAN 10UF 6.3WV
C22 C92-0502-05 CHIP-TAN 0.33UF 35WV
C24 CK73HB1H102K CHIP C 1000PF K
C25 CC73HCH1H020B CHIP C 2.0PF B
C26 CC73HCH1H300J CHIP C 30PF J
C27 C92-0697-05 CHIP-TAN 3.3UF 16WV
C29 ,30 CK73HB1H471K CHIP C 470PF K
C32 C92-0001-05 CHIP C 0.1UF 35WV
C33 ,34 CK73HB1H102K CHIP C 1000PF K
C35 CC73HCH1H270J CHIP C 27PF J
TX-RX UNIT (X57-6870-20)

Kenwood TK-2202 Specifications

General

Frequency Range	136-174 MHz
Channel Capacity	16
Power Output	5W
Channel Spacing	12.5/25 kHz
Operating Voltage	7.5V
Ingress Protection	IP54
Modulation	FM
Voltage	7.5V
Type	Portable
MIL-STD	MIL-STD-810
