Kenyon 213 - Installation Instructions

3
KENYON

Model #
Stove Description Voltage AC Rated Wattage
(W) & Amps (A)
Suggested Wire Size Based On Wire
Run Length - d (feet) One Way
B61044 213 A/E w/ Black
Glass Lid
120 Volts - 60 Hz 1100 W / 10 A
d < 35 feet : 14 AWG
35 < d < 80 feet: 12 AWG
B61045 213 A/E w/ Black
Glass Lid
240 Volts - 50/60 Hz 1100 W / 5 A
d < 125 feet: 14 AWG
B61046 213 A/E w/ White
Glass Lid
120 Volts - 60 Hz 1100 W / 10 A
d < 35 feet : 14 AWG
35 < d < 80 feet: 12 AWG
B61047 213 A/E w/ White
Glass Lid
240 Volts - 50/60 Hz 1100 W / 5 A
d < 125 feet: 14 AWG
B61048 436 A/E w/ Black
Glass Lid
120 Volts – 60 Hz 2200 W / 20 A
d < 20 feet: 14 AWG
20 < d < 45 feet: 12 AWG
45 < d < 70 feet: 10 AWG
B61049 436 A/E w/ Black
Glass Lid
240 Volts - 50/60 Hz 2200 W / 10 A
d < 90 feet: 14 AWG
INSTALLATION INSTRUCTIONS
NOTE: Installation should comply with ABYC standard A-3, “Recommended Practices and Standards
Covering Galley Stoves,” and/or the “Fire Protection Standards for Motorcraft” NFPA #302.
MOUNTING THE ALCOHOL COOKTOP
LOCATING THE COOK TOP AWAY FROM FLAMMABLE MATERIALS
Before you cut your countertop: Make certain the Cook Top will be far enough from flammable
materials!
! CAUTION
Do not cut the opening in your countertop until you ensure that there will be adequate horizontal
and vertical clearances from the Cook Top to the nearest flammable materials- fabric, plastic,
wood- (except the countertop itself).
Minimum Distances are:
40cm (16”) Horizontally 1M (39”) Vertically
It is the installer’s and/or purchaser’s responsibility to ensure that the Cook Top is installed in a
location such that a fire hazard is not created.
IN EUROPE:
Contact the authorities appointed by the government in each separate country
IN USA
:
Contact ABYC, 3069 Solomons Island Road, Edgewater Maryland 21037-1416
tel (410) 956 1050 fax (410) 956 2737 internet abycinc@aol.com
