KERN ADB 200-4 User Manual

ADB-BA-e-1510 29
11.2 Interface cable:
Balance
9-poles
PC
9-poles
2 2
3 3
5 5
Balance
9-poles
Printer
25-
poles
2 2
3 3
5 7
11.3 Interface parameters
11.3.1 Baud rate
In this menu point the data transfer is adapted to different RS232C-peripheral
devices. The baud rate determines the speed of the data transfer via the serial
interface. For a faultless data transfer, balance and peripheral device must be set to
the same value.
Call up menu item „C3“, see chap. 10.1
Use the PRINT key to select the desired setting.
Options:
C4 - 0 2400 baud
C4 - 1 1200 Baud
C4 - 2 4800 baud
C4 - 3 9600 baud
Save / back to weighing mode, see chap. 10.1
