KERN ADB-A Series Operating Instruction

28 ADB_ADJ-BA-e-1830
12.2 Interface cable
Balance
9-poles
PC
9-poles
2 3
3 2
5 5
Balance
9-poles
Printer
9-poles
2 3
3 2
5 5
12.3 Interface parameters
12.3.1 Baud rate
In this menu point the data transfer is adapted to different RS232C-peripheral
devices. The baud rate determines the speed of the data transfer via the serial
interface. For a faultless data transfer, balance and peripheral device must be set to
the same value.
Call up menu item „C3“, see chap. 11.1
Use the PRINT key to select the desired setting.
Options:
C4 - 0 1200 Baud
C4 - 1 2400 baud
C4 - 2 4800 baud
C4 - 3 9600 baud
Save / back to weighing mode, see chap. 11.1
