EN
23
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
2. The minimum installation height is 85cm.
3.The rear surface of appliance shall be placed against a wall. Leave a minimum cle-
arance of 30cm above the oven, a minimum clearance of 20cm is required between
the oven and any adjacent walls.
4. Do not remove the legs from the bottom of the oven.
5.Blocking the intake and/or outlet openings can damage the oven.
6.Place the oven as far away from radios and TV as possible. Operation of micro-
wave oven may cause interference to your radio or TV reception.
7.Plug your oven into a standard household outlet. Be sure the voltage and the frequ-
ency is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing
appliance. If installed near or over a heat source, the oven could be damaged and the
warranty would be void.
The accessible surface may be hot during operation.
20cm
30cm
20cm
min85cm
0cm
Installation
1.Select a level surface that provide enough open space for the intake and/or outlet
vents.
