Fahrantrieb KDM 35 Zusammenbau
Stand
30.09.2009
C00164 ADX
Nr. Art.-Nr. Anz. Benennung
1 C00012 1 Hydraulic motor production console
2 903 012 100 1 Eye bolt
3 905 112 000 8 U disk
4 900 012 002 3 Stop nut
5 901 012 055 1 Skt.-screw
6 920 101 648 1 Drive chain
7 935 111 040 1
Hydraulic motor connected to the
page
8 C00163 1 Engine mounts
9 905 006 000 4 Spring ring
10 901 006 020 3 Skt.-screw
11 920 401 012 1 Sprockets Z12
12 701 301 503 1 Scheibe D26, 3 x 16, 3 x 2
13 905 206 025 1 K disk
14 901 006 016 1 Skt.-screw
15 908 005 516 1 Key A5x5x16
16 901 012 035 1 Skt.-screw
