32
EN
tion is required, the automation system must be
combined with other devices;
the product may not be used until the automation
system “commissioning” procedure has been per-
formed as specied in the “Automation system te-
sting and commissioning” section;
the system power supply line must include a circuit
breaker device with a contact gap allowing com-
plete disconnection in the conditions specied by
class III overvoltage;
use unions with IP55 or higher protection when
connecting hoses, pipes or cable glands;
the electrical system upstream of the automation
system must comply with the relevant regulations
and be constructed to good workmanship stan-
dards;
this appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been gi-
ven supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved;
before starting the automation system, ensure that
there is no-one in the immediate vicinity;
before proceeding with any cleaning or mainte-
nance work on the automation system, disconnect
it from the electrical mains;
special care must be taken to avoid crushing
between the part operated by the automation sy-
stem and any xed parts around it;
children must be supervised to ensure that they do
not play with the equipment.
Frequently examine the installation for imba-
lance where applicable and signs of wear or
damage to cables, springs and mounting.
Do not use if repair or adjustment is necessary.
Since the automation system exceeds 10 kg in
weight, it must be handled using a truck (IEC
60335-2-103:2015)
The automation system component packaging
material must be disposed of in full observan-
ce of current local waste disposal legislation.
KEY AUTOMATION reserves the right to amend
these instructions if necessary; they and/or
any more recent versions are available at www.
keyautomation.it
2 - INTRODUCING THE PRODUCT
2.1 - Technical characteristics
ATTENTION !
ATTENTION !
ATTENTION !
DATI TECNICI
900ALT324KF 900ALT324LFK
900ALT424K 900ALT424LK 900ALT624K 900ALT624LK
Torque 40 Nm 200 Nm 305 Nm
Temporary service 50 % 80 % 80 %
Opening time 90° 1 sec 3,5 sec 6 sec / 12 sec*
Control unit CT10224F CT10224 CT10224
Max. number of transmitters storage
FIX CODE
150 transmitters
Max. number of transmitters storage
ROLLING CODE
150 transmitters
Power supply
230 V ±10%
50-60Hz
120 V ±10%
50-60Hz
230 V ±10%
50-60Hz
120 V ±10%
50-60Hz
230 V ±10%
50-60Hz
120 V ±10%
50-60Hz
230 Vac power supply line fuses 1.6 A slow-acting
Standby power 10 W
(1)
10 W
(1)
10 W
(1)
Rated power 30 W 40 W 40 W
Maximum input power 60 W 90 W 100 W
Red and green light integrated yes yes yes
Red and green light bar no yes yes
Sound pressure < 70 dB(A) < 70 dB(A) < 70 dB(A)
Protection class IP 54 IP 54 IP 54
