10
EN
2 - INTRODUCING THE PRODUCT
3 - PRELIMINARY CHECKS
Before installing the product, perform the following checks and in-
spections:
check that the barrier is suitable for automation;
the weight and size of the barrier must be within the operating limits
specied for the automation system in which the product is installed;
check that the barrier has rm, effective mechanical safety stops;
make sure that the product xing zone is not subject to ooding;
high acidity or salinity or nearby heat sources might cause the pro-
duct to malfunction;
in case of extreme weather conditions (e.g. snow, ice, wide tempe-
rature variations or high temperatures), friction may increase, cau-
sing a corresponding rise in the force needed to operate the system;
the starting torque may therefore exceed that required in normal
conditions;
check that when operated by hand the barrier moves smoothly wi-
thout any areas of greater friction or derailment risk;
check that the barrier is well balanced and will therefore remain sta-
tionery when released in any position;
check that the electricity supply line to which the product is to be
connected is suitably earthed and protected by an overload and dif-
ferential safety breaker device;
the system power supply line must include a circuit breaker device
with a contact gap allowing complete disconnection in the condi-
tions specied by class III overvoltage;
ensure that all the material used for installation complies with the
relevant regulatory standards.
2.1 - Technical characteristics
TECHNICAL SPECIFICATIONS 900ALT424 900ALT624 900ALT242K 900ALT624K
Torque
200 Nm 250 Nm 200 Nm 250 Nm
Temporary service
80 % 80 % 80 % 80 %
Opening time
3,5 sec 6/*12 sec 3,5 sec 6/*12 sec
Control unit
CT10224 CT10224 CT10224 CT10224
Power supply
Vac (Vdc) 230 (24) Vac (Vdc) 230 (24) Vac (Vdc) 230 (24) Vac (Vdc) 230 (24)
Motor absorption
1,3 A 1,3 A 1,3 A 1,3 A
Input power
300 W 300 W 300 W 300 W
Integrated lights
- - yes yes
Protection class
IP 54 IP 54 IP 54 IP 54
Dimensions (L-P-H)
320-220-1000 mm 400-280-1051 mm 360-220-1110 mm 450-280-1188 mm
Weight
46 Kg 66 Kg 47 Kg 67 Kg
Operating temperature
-20 °C + 55 °C -20 °C + 55 °C -20 °C + 55 °C -20 °C + 55 °C
Maximum length of rod
4 m 6*(8 mt) 4 m 6*(8 mt)
* with 8 m bar
