KD-S4x1X-2 Help Command (H). Returns entire API in readable format:
KD-S4x1X-2> H
-------------------------------------------------------------------------
-- Key Digital Systems HELP --
-------------------------------------------------------------------------
-- KD-S4x1X-2 F/W Version : 1.01 --
-- --
-- H : Help --
-- STA : Show Global System Status --
-- --
-- Video Output Setup Commands: yy = [01-04,U,D] --
-- SPO SI yy : Set Output to Video Input yy --
-- SPO01 SI yy : Set Output to Video Input yy --
-- --
-- System Control Setup Commands: --
-- SPC AS x : Set Auto Sensing Mode x = [0=OFF,1=ON] --
-- SPC FB E/D : Enable/Disable Front Input Select Button --
-- --
-------------------------------------------------------------------------
KD-S4x1X-2 Status Command (STA). Returns unit status and settings in readable format:
KD-S4x1X-2> STA
-------------------------------------------------------------------------
-- Key Digital Systems STATUS --
-------------------------------------------------------------------------
-- KD-S4x1X-2 F/W Version : 1.01 --
-- --
-- Front Input Select Button : Enabled --
-- Auto Sensing Mode : OFF --
-- --
-- Video Input 01 : EDID = DEFAULT A, LINK = ON --
-- Video Input 02 : EDID = DEFAULT A, LINK = OFF --
-- Video Input 03 : EDID = DEFAULT A, LINK = ON --
-- Video Input 04 : EDID = DEFAULT A, LINK = OFF --
-- --
-- Video Output : Input = 01, LINK = ON , HPD = OFF --
-- --
-------------------------------------------------------------------------
Specifications
Technical:
› Input (Each): HDMI Connector, Type A, 19 Pin Female
› Output: HDMI Connector, Type A, 19 Pin Female
› Bandwidth: TMDS bandwidth 18 Gbps
› DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
› HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
› Power Supply: SK01T-0500100Z 5V/1A DC power jack, screw-in type
General:
› Regulation: CE, RoHS, WEEE
› Enclosure: Black Metal
› Product:
» KD-S2x1X-2 - 5.8 x 3.5 x 0.8” (147 x 90 x 20mm), 0.8 lb
» KD-S4x1X-2 - 7.7 x 3.5 x 0.8” (197 x 90 x 20mm), 0.9 lb
› Packaging:
» KD-S2x1X-2 - 8.3 x 5.6 x 3.1” (210 x 144 x 80mm), 1.2 lb
» KD-S4x1X-2 - 9.4 x 5.6 x 3.1” (240 x 144 x 80mm), 1.3 lb
