Code Description
REVO2024 24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, 230 Vac
REVO2024S 24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, without control unit
REVO20110 24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, 110 Vac
TECHNICAL DATA
MODELS REVO2024 REVO2024S REVO20110
TECHNICAL SPECIFICATIONS
Torque Nm 120 120 120
Working cycle % 80 80 80
Opening time at 90° sec adjustable adjustable adjustable
Control board 14A - 14A
Power supply Vac (Vdc) 230 (24) (24) 110 (24)
Absorption A 0,5 2 1
Engine power W 100 50 100
Integrated lights yes yes yes
Degree of protection IP 44 44 44
Dimensions (L - P - H) mm 120 - 250 - 350 120 - 250 - 350 120 - 250 - 350
Weight Kg 10,5 8 10,5
Operating temperature °C -20°+55° -20°+55° -20°+55°
Leaves maximum weight Kg 250 250 250
2 - PRODUCT OVERVIEW
2.1 - Description of the product
The RÉVO gear motors are destined to be installed in systems for the
automation of gates with hinged doors.
The RÉVO gear motors have been designed and constructed to be
tted onto hinged doors within the weight limits indicated in the
technical specications table.
The use of gear motors for applications which differ from those
indicated above is prohibited.
2.2 - Model and technical characteristics
3 - PRELIMINARY CHECKS
Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the maxi-
mum permissible operating limits specied in Fig. 2
- Check the presence and strength of the security mechanical stops
of the gate or door
- Check that the mounting area of the product is not subject to ood-
ing
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
starting point may be higher than under normal conditions.
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if left
in any position
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
differential security device
- Provide the power system with a disconnecting device with a gap
of contacts enabling full disconnection under the conditions dictated
by the overvoltage category III.
- Ensure that all materials used for the installation comply with cur-
rent regulations
