1. Download the right firmware for your keyboard from our website. Remove
the power cable from the keyboard.
2. Remove the space bar keycap to find the rest button on the PCB.
3. Hold the reset key while plugging In the power cable. The keyboard now will
enter DFU mode.
4. Flash the firmware with the QMK Toolbox. (Make sure to choose the
atmega32u4 as the MCU)
5.
Q1 Keyboard Specifications
Layout
75%
Swatch type
Mechanical
Width
145 mm
Length
327.5 mm
Front height
21.8 mm (wiMout keycaps)
Back height
34.8 mm (without keycaps)
Front height
32.2 mm (with OEM keycaps Installed)
Back height
44.2 mm (with OEM keycaps installed)
Keyboard feet height
2.4 mm
Angle
5.2 degree
Q1 Mechanical Keyboard Overview
