１０．specification
Model name RCS05
Frequency 76.5GHz (76-77GHz) Occupied frequency bandwidth: 1GHz
RF Output Power + 6dBm typ. (+8～+4dBm) Ant gain: 35dBi EIRP: +41dBm typ. (+43～+39dBm)
Radar system Pulse radar Emission identifier: P0N
pulse width: 5ns
pulse repetition frequency:1MHz
Rated Supply Voltage +12V DC
Horizontal Detection
33°
Angle steps for
horizontal
0.5°
Angle resolution 3°
Sensitivity for
distance(RCS10dBsm)
50m
Accuracy for distance
15cm
Resolution for distance
1m
Display • Image
• RCS of an object or enclosed part
• Signal strength of specified part
Record • 2D data（Get on screen refresh time）
• 3D data（You need the HDD. You need ten times the time in 2D data）
External output • Clock output for camera synchronization (for shooting radar screens and camera photos
at the same time)
Vertical Detection angle 20°
Angle steps for horizontal 2° Screen Refresh Time 0.9 seconds
Angle steps for horizontal 0.5° Screen Refresh Time 4 seconds
Vertical Detection angle 10°
Angle steps for horizontal 1° Screen Refresh Time 0.8 seconds
Angle steps for horizontal0.5° Screen Refresh Time 2 seconds
Vertical Detection angle 5°
Angle steps for horizontal 0.5° Screen Refresh Time 0.7 seconds
Vertical Detection angle 0°
Screen Refresh Time 0.1 seconds
