Keysight Technologies E8257D Configuration Guide

4
Step 10. Choose instrument connector configuration and accessories
Note: Option 520 and 521 instruments ship with a 3.5 mm (m) RF output connector on the front panel.
Option 532, 540, and 550 instruments ship with a 2.4 mm (m) RF output connector on the front panel.
Option 567 instruments ship with a 1.85 mm (m) RF output connector on the front panel.
Ordering number Description Purpose Requires
Standard with 3.5 mm (f) to 3.5 mm (f) Adapter is included with the purchase of the
E8257D-520 and -521 connector adapter 20 GHz models to connect to 3.5 mm (m)
Standard with 2.4 mm (f) to 2.4 mm (f) and Adapter set is included with the purchase of the
E8257D-532, -540, 2.4 mm (f) to 2.9 mm (f) 32, 40 and 50 GHz models to connect to 2.4 mm (m)
and -550 connector adapter(s)
Standard with 1.85 mm (f) to 1.85 mm (f) and Adapter set is included with the purchase of
E8257D-567 2.4 mm (f) to 2.9 mm (f) connector adapter(s) the 67 GHz models to connect to 1.85 mm (m)
E8257D-1ED
1
Type-N (f) RF output connector Type-N (m) to 3.5 mm (f) adapter is included
with the purchase of the type-N (m) connector
E8257D-1EM
2
Moves all front panel connectors to the Simplifies cable management in rack mount environments
rear panel
E8257D-C09 Moves all front panel connectors to the Simplifies cable management in rack mount E8257D-1EM
rear panel except the RF output connector environments
E8257D-1CM Rackmount flange kit Provides a flange kit to mount the signal
generator into a standard EIA 19” rack
E8257D-1CN Front handle kit Provides front handles for carrying the
instrument (not for rack mount)
E8257D-1CP Rackmount kit with front handles Provides front handles and a flange kit to mount
the signal generator into a standard EIA 19” rack
E8257D-1CR Rack slide kit Provides a non-tilting rack slide kit
E8257DS15 OML Inc.
3
model number S15MS-AG at +8 dBm Millimeter source module, 50 GHz to 75 GHz E8257D-1EU
E8257DS12 OML Inc.
3
model number S12MS-AG at +6 dBm Millimeter source module, 60 GHz to 90 GHz E8257D-1EU
E8257DS10 OML Inc.
3
model number S10MS-AG at +5 dBm Millimeter source module, 75 GHz to 110 GHz E8257D-1EU
E8257DS08 OML Inc.
3
model number S08MS-AG at –5 dBm Millimeter source module, 90 GHz to 140 GHz E8257D-1EU
E8257DS06 OML Inc.
3
model number S06MS-AG at –9 dBm Millimeter source module, 110 GHz to 170 GHz E8257D-1EU
E8257DS05 OML Inc.
3
model number S05MS-AG at –15 dBm Millimeter source module, 140 GHz to 220 GHz E8257D-1EU
E8257DS03 OML Inc.
3
model number S03MS-AG at –25 dBm Millimeter source module, 220 GHz to 325 GHz E8257D-1EU
E8257DS02 OML Inc.
3
model number SM02MS-AG Millimeter source module, 325 GHz to 500 GHz E8257D-1EU
at –27 dBm
E8257DV15
4
VDI model number WR15 SGX Millimeter frequency extension module,
50 to 75 GHz at +20 dBm
E8257DV12
4
VDI model number WR12 SGX Millimeter frequency extension module,
60 to 90 GHz at +15 dBm
E8257DV10
4
VDI model number WR10 SGX Millimeter frequency extension module,
75 to 110 GHz at +14 dBm
E8257DV08
4
VDI model number WR08 SGX Millimeter frequency extension module,
90 to 140 GHz at +9 dBm
E8257DV06
4
VDI model number WR6.5 SGX Millimeter frequency extension module,
110 to 170 GHz at +8 dBm
E8257DV05
4
VDI model number WR5.1 SGX Millimeter frequency extension module,
140 to 220 GHz at +4 dBm
E8257DV03
4
VDI model number WR3.4 SGX Millimeter frequency extension module,
220 to 330 GHz at – 2 dBm
E8257DV2B
4
VDI model number WR2.8 SGX Millimeter frequency extension module,
260 to 400 GHz at – 6 dBm
E8257DV02
4
VDI model number WR2.2 SGX Millimeter frequency extension module,
325 to 500 GHz at – 10 dBm
E8257DV1B
4
VDI model number WR1.5 SGX Millimeter frequency extension module,
500 to 750 GHz at – 21 dBm
E8257DV01
4
VDI model number WR1.0 SGX Millimeter frequency extension module,
750 to 1100 GHz at – 23 dBm
U3035P Distribution network - PSG Distribute master LO signal to multiple signal E8257D-HCC
generators for phase coherent applications
1. Option 1ED is not compatible with frequency options E8257D-532, -540, -550, or -567.
2. Not compatible with Option 1SM (scan modulation).
3. Oleson Microwave Labs, Inc.
4. E8257DVxx frequency extension modules require an N5262VDI-175 external power supply.
