5
Installation Kit Parts List
E8251-60417
(For instruments with serial prefix < US4805/MY4805)
E8251-60980
(For instruments with serial prefix ≥ US4805/MY4805)
Item Quantity Description Part Number
1 2 Screw M3 x 0.5 8mm–lg 0515-0372
2 2 Screw M3 x 0.5 4mm–lg 0515-0663
3 3 Cable Tie 1400-0249
4 1 Termination-SMA male coaxial 50 ohm 1810-0118
5 2 Inductor–Fixed 470nH ± 2% 9140-2044
6 1 Bracket, Adapter, Reference Oscillator E8251-00338
7 1 Cable Assy semi–rigid, UNX 1 GHz E8251-20384
8 1 A7 Reference Board Assy (Option UNX) E8251-60648
9 1 A32 10 MHz Crystal Oscillator–UNX E8251-60626
10 1 Installation Note, UNX Upgrade Kit E8251-90309
11 1 Entitlement Certificate n/a
Item Quantity Description Part Number
1 2 Screw M3 x 0.5 4mm–lg 0515-0663
2 1 Bracket, Adapter, Reference Oscillator E8251-00338
3 1 A32 10 MHz Crystal Oscillator–UNX E8251-60626
4 1 Installation Note, UNX Upgrade Kit E8251-90309
5 1 Entitlement Certificate n/a
