PNA Network Analyzers
1
E8361A/62B/63B/64B, N5250A
PNA (Highest performance series) PNA (Highest performance series)
E8362B 10 MHz to 20 GHz E8361A 10 MHz to 67 GHz
E8363B 10 MHz to 40 GHz N5250A
2
10 MHz to 110 GHz
E8364B 10 MHz to 50 GHz
Options
To add options to a product, order the corresponding item number.
Description For E8362B For E8363B For E8364B For E8361A For N5250A
system
3
Additional information
Test set
Option 014
– Configurable test set
E8362B-014 E8363B-014 E8364B-014 E8361A-014 Included
Power configuration
Option UNL
– Extended power range
and bias-tees
E8362B-UNL E8364B-UNL E8364B-UNL E8361A-UNL Included Only E8361A requires 014
Option 016
– Add receiver attenuators
E8362A-016 E8364A-016 E8364A-016 E8361A-016 E8361A-016 Requires UNL (only
E8361A also requires 014)
Option H85
– High-power configuration
E8362B-H85 E8363B-H85 E8364B-H85 Contact
Keysight
Contact
Keysight
Includes 014, 016, UNL*4,
080, 081
Non-linear measurements
Option 080
– Frequency offset
E8362A-080 E8364A-080 E8364A-080 E8361A-080 Included Requires 014 (E8361A
only, 081 required if UNL
is also purchased)
Option 081
– Reference receiver switch
E8362A-081 E8364A-081 E8364A-081 E8361A-081 Included Requires 014, 080 (only
E8361A also requires UNL)
Option 082
– Scalar-calibrated
converter measurements
E8362B-082 E8363B-082 E8364B-082 E8361A-082 E8361A-082
5
Requires 014, 080
Option 083
– Vector- and scalar-calibrated
converter measurements
E8362A-083 E8364A-083 E8364A-083 E8361A-083 E8361A-083
5
Requires 014, 080, 081
(only E8361A also
requires UNL)
Option 084
6
– Embedded LO Measurement
E8362B-084 E8363B-083 E8364B-083 E8361A-083 Requires Option 083
Pulse, antenna, mm-wave
Option H08
– Pulsed-RF measurement
capability
E8362B-H08 E8363B-H08 E8364B-H08 E8361A-H08 E8361A-H08
5
Requires 014, 080
Option H11
– IF access (for antenna,
pulsed-RF and mm-wave
measurements)
E8362B-H11 E8363B-H11 E8364B-H11 E8361A-H11 Included Requires 014, UNL, 080,
and 081
Measurement features
Option 010
Option 550
Option 551
– Time-domain capability
– 4-port measurement appli-
cation
– N-port capabilities
E8362A-010
E8362B-550
E8362B-551
E8363A-010
E8363B-550
E8363B-551
E8364A-010
E8364B-550
E8364B-551
E8361A-010
E8361A-550
E8361A-551
E8361A-010 Options 550 and 551
require 014, and are not
compatible with N5250A
systems
Accessories
Option 1CM
– Rack mount kit for use without
handles
E8362A-1CM E8363A-1CM E836 4A-1CM E8361A-1CM E8361A-1CM
Option 1CP
– Rack mount kit for use
with handles
E8362A-1CP E8363A-1CP E8364A-1CP E8361A-1CP E8361A-1CP
N4688A
– USB CD R/W drive
N4688A N4688A N4688A N4688A N4688A
N4689A
– USB Hub
N4689A N4689A N4689A N4689A N4689A
Calibration documentation
Option 1A7
– ISO 17025 compliant
calibration
E8362B-1A7 E8363B-1A7 E8364B-1A7 E8361A-1A7
E8361A-1A7
Option UK6
– Commercial calibration
certificate with test data
E8362A-UK6 E8363A-UK6 E8364A-UK6 E8361A-UK6 E8361A-UK6
Option A6J
– ANSI Z540 compliant
calibration
E8362B-A6J E8363B-A6J E8364B-A6J E8361A-A6J E8361A-A6J
1. All models are not available in all countries.
2. For more detailed information regarding the 110 GHz network analyzer system, refer
to the Keysight Web site: www.keysight.com/nd/pna and download the N5250A
Technical Overview, literature number 5988-9620EN.
3. The N5250A 110 GHz system also includes an N5260A millimeter-wave test set
controller, 1.0 mm combiner assembly, interconnecting cables, and installation and
productivity assistance. See page 14 for more details.
4. UNL* does not include bias-tees. Only includes source attenuators.
5. Up to 67 GHz.
6. Requires rmware A.07.05 and above plus 1.1 GHz CPU board.
Note: Item numbers may not correspond to product model number. For
example, to order the time-domain option on the E8362B,
the correct item number to order is E8362A-010.
Calibration Three year calibration plans are available at time
of instrument purchase.
