Keystone F792 User Manual

© Copyright by Tyco International Ltd. F792LPSB/11/98
Keystone reserves the right to change product designs and specifications without notice.
Controls – F792 Switchbox LP Series
Option 1 Low profile switchbox with
two V9 single pole double
throw microswitches
Electrical Switch Plan Electrical Switch Wiring Diagram
Proximity Plan Proximity Wiring Diagram
Option 3 Low profile switchbox with
two pneumatic switches
Pneumatic Switch Plan Pneumatic Switch Wiring Diagram
(Shown in mid travel)
Top
switch
(open)
Bottom
switch
(closed)
Mains
Supply
Output
to lamp
Output
to lamp
Yellow
Black
Red
Brown
Blue
G/Y
Earth
NC
123456
NC
Top
switch
(open)
Bottom
switch
(closed)
Black (A)
Blue (-)
Brown (+)
Black (A)
Brown (+)
Earth
123456
NC NPN PROX
10 – 30V DC 200mA MAX
(Shown in mid travel)
Top
sensor
(open)
Bottom
sensor
(closed)
Blue (-)
Brown(+)
Blue (-)
Brown (+)
Earth
123456
NAMUR SENSOR
8V DC
(shown in closed position)
Top
switch
(open)
open
signal
pressure
source
close
signal
Bottom
switch
(closed)
Open signal
1/8" BSP.T
Shut signal
1/8" BSP.T
Air supply
1/8" BSP.T
Note:
2 Wire Schematic Illustrated.
Note:
3 Wire Schematic Illustrated.
Caution:
Reverse air connections will
cause venting into enclosure.
