KHADAS VIM1S - Hardware Interfaces and Components; External Connectivity Ports; On-board Connectors and Features

USB 2.0
(500mA)
10/100M
LAN
HDMI
(Output)
USB-C
(5V)
USB 2.0
(750mA)
VIN Input
(5V)
Micro-SD
(SDXC)
MHF2
Antennas
(WiFi & BT)
PWM
Fan
Header
Reset
Programm-
able MCU
(STM8S003)
LED
(White & Red)
Function
Power
RTC
Header
XPWR
Pads
2-Channel
Infrared
40-Pin Header
(I2C, I2S, UART, PWM,
SPI Flash IO
ADC, USB, S/PDIF, MCU-I/O)
3 4 5 6
Interfaces
Interfaces
IO
R
F
P
VIM1S V11
2206 2228
20
1
40
21
FAN
