5
Always check the Owner’s Manual for complete operating information and safety warnings.
A
Tachometer: The tachometer indicates number of engine revolutions per minute.
B
Engine Temperature Gauge: This gauge shows the temperature of the engine coolant. If the needle
nears the “H” position on the gauge, it indicates
an overheating engine. Do not drive your
vehicle in this condition.
C
Turn Signal Indicators: The
indicator will illuminate when the
turn signal control is engaged.
D
Shift Pattern Indicator:
Indicates shift lever selection.
(Automatic Transmission only).
E
Odometer: The odometer indicates
the total distance the vehicle has been driven.
F
Speedometer: Indicates speed of vehicle.
G
Fuel Gauge: Displays approximate amount of
fuel remaining in the vehicle.
0
10
20
20
40
60
80
100
120
MPH
km/h
140
160
180
200
220
30
40
50
60
70
80
90
100
110
120
130
140
0
1
2
3
4
5
6
7
8
x1000rpm
H
C
F
E
CRUISE SET
R
I
E
E
INSTRUMENT CLUSTER
F
E
A
B
D
G
H
C
*If equipped.
Tire Pressure Monitoring System (TPMS) Detects loss of tire pressure beyond specifi c limits. A warning
indicator
will alert the driver of tire(s) with a low pressure condition, check/correct to extinguish warning
light. If the letters
TPMS appear and remain illuminated, this indicates the Tire Pressure Monitoring System is
not functioning properly. Consult your dealer for service. For proper maintenance, safety, and maximum fuel
economy, you must always maintain recommended tire infl ation pressures and stay within the load limits and
weight distribution recommended for your vehicle.
H
Tripmeter: The tripmeter can record individual trip
distances for up to two different trips (A or B). The
tripmeter button (located in the center console) will
reset the meter to “0” if pressed longer than 1 second.
C
