Maintenance
728
Fuse Name Fuse rating Circuit Protected
MULTI
FUSE
MDPS 1 80A MDPS Unit (Column)
COOLING
FAN 2
60A [G4KH/G4FJ] Cooling Fan1 Relay, Cooling Fan2 Relay
COOLING
FAN 1
50A [G4KJ] Cooling Fan1 Relay
B+ 3 50A Smart Junction Block (IPS 2 (IPS 5), IPS 3 (IPS 6), IPS 7, IPS 8)
REAR
HEATED
50A Rear Heated Relay
DCT1 40A [G4FJ-DCT] TCM
BLOWER 40A Blower Relay
POWER
OUTLET 1
40A Power Outlet Relay
IG2 30A [W/O Smart Key] Start Relay, Ignition Switch, [With Smart Key] Start Relay, PCB Block (IG2 Relay)
MDPS 2 100A MDPS Unit (Rack)
B+1 60A
Smart Junction Block (Fuse - SUNROOF1, SUNROOF2, S/HEATER RR, P/SEAT DRV, P/SEAT PASS,
P/WINDOW LH, P/WINDOW RH, TRUNK)
B+5 60A PCB Block (Engine Control Relay, Fuse - TCU1, ECU2, FUEL PUMP, HORN, WIPER1)
B+2 60A Smart Junction Block (IPS 1, IPS 4, Fuse - AMP, S/HEATER FRT)
ABS 1 40A ESC Module
IG1 40A [W/O Smart Key] Ignition Switch, [With Smart Key] PCB Block (IG1/ACC Relay)
DCT 2 40A [G4FJ-DCT] TCM
ABS 2 30A ESC Module, Multipurpose Check Connector
Engine room compartment fuse panel
