Maintenance
Fuse Name Fuse rating Circuit Protected
FUSE
B+4 40A
Smart Junction Block (Leak Current Autocut Device Fuse - INTERIOR LAMP, MEMORY1, MULTI
MEDIA, Fuse - DOOR LOCK, MODULE1, SMART KEY, BRAKE SWITCH)
E-CVVT 1 40A E-CVVT Relay
VACUUM
PUMP 1
20A Vacuum Pump
DEICER 20A Deicer Relay
AMS 10A Battery Sensor
E-CVVT 2 20A PCM
A/CON 10A A/C Control Module
E-CVVT 3 20A PCM
HEATED
MIRROR
10A A/C Control Module, Driver/Passenger Power Outside Mirror, ECM
WIPER 2 10A BCM, PCM/ECM
H/LAMP HI 20A Head Lamp HI Relay
