Maintenance
748
Fuse Name Fuse rating Circuit Protected
FUSE
FUEL PUMP 20A Fuel Pump Relay
ECU 1 20A PCM/ECM
SENSORS 2 10A
E/R Junction Block (Fuel Pump Relay, Cooling Fan 1/2 Relay)
[G4KJ] Oil Control Valve (Exhaust), Purge Control Solenoid Valve, Variable Intake Solenoid Valve, Canister
Close Valve
[G4KH] Oil Control Valve (Exhaust), Purge Control Solenoid Valve, RCV Control Solenoid Valve, Canister
Close Valve
[G4FJ] Oil Control Valve #1/#2, Purge Control Solenoid Valve, RCV Control Solenoid Valve, Canister Close
Valve
TCU 2 15A Transaxle Range Switch, TCM
ABS 3 10A ESC Module, Multipurpose Check Connector
POWER
OUTLET 3
20A Rear Power Outlet
B/UP LAMP 10A PCM/TCM, Transaxle Range Switch, Audio, Electro Chromic Mirror, Rear Combination Lamp (IN) LH/RH
SENSOR 1 15A Oxygen Sensor (Up/Down)
IGN COIL 20A Ignition Coil #1/#2/#3/#4
ECU 2 10A PCM/ECM
TCU 1 10A PCM/TCM
VACUUM
PUMP 2
10A Vacuum Pump, Vacuum Switch
ECU 3 10A PCM/ECM
POWER
OUTLET 2
20A Front Power Outlet #1
HORN 20A Horn Relay, ICM Relay Box (Burglar Alarm Horn Relay)
WIPER 1 30A Wiper Power Relay
